Type FL-A2-CE Flange Head Closed End Rivet Nuts, Round Plain Body A2 Stainless
Product Details
These flange head style rivet nuts offer excellent push-out & torque-out performance in predrilled or punched holes without any extra hole preparation. The closed end design prevents ingress of moisture or contamination and also prevents too long a screw being inserted into the component. Rivet nuts are installed from one side only using a pneumatic, cordless or hand rivet nut tool.
Type FL-A2-CE features
- Flange Head Style
- Round Plain Body
- Closed End
- A2 / 304 Stainless Steel
Specification
| Thread Size | Grip Range | Gripmor Part No | Hole Diameter | Body Diameter | Head Diameter | Head Thickness | Overall Length |
| M4 | 0.5-2.5 | FL4-A2-CE | 6.1 | 6 | 9 | 1 | 17 |
| M5 | 0.5-3.0 | FL5-A2-CE | 7.1 | 7 | 10 | 1 | 19 |
| M6 | 0.5-3.0 | FL6-A2-CE | 9.1 | 9 | 12 | 1.5 | 22.5 |
| M6 | 3.0-5.0 | FL6-5.0-A2-CE | 9.1 | 9 | 12 | 1.5 | 25 |
| M8 | 0.5-3.0 | FL8-A2-CE | 11.1 | 11 | 15 | 1.5 | 25 |
| M8 | 3.0-5.5 | FL8-5.5-A2-CE | 11.1 | 11 | 15 | 1.5 | 27.5 |
| M10 | 1.0-3.5 | FL10-A2-CE | 13.1 | 13 | 17 | 2 | 28.5 |
Dimensions in mm
